MCD -6550 Airport X ray Scanner , X ray Baggage Scanner 34mm steel Penetration

China MCD -6550 Airport X ray Scanner , X ray Baggage Scanner 34mm steel Penetration supplier
MCD -6550 Airport X ray Scanner , X ray Baggage Scanner 34mm steel Penetration supplier MCD -6550 Airport X ray Scanner , X ray Baggage Scanner 34mm steel Penetration supplier MCD -6550 Airport X ray Scanner , X ray Baggage Scanner 34mm steel Penetration supplier MCD -6550 Airport X ray Scanner , X ray Baggage Scanner 34mm steel Penetration supplier

Large Image :  MCD -6550 Airport X ray Scanner , X ray Baggage Scanner 34mm steel Penetration

Product Details:

Place of Origin: China
Brand Name: MCD
Certification: ISO , CE
Model Number: MCD-5030A

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden Case Pacakge
Delivery Time: Normally within 5 working days
Payment Terms: T/T , Western Union , L/C
Supply Ability: 300 set/month
Contact Now
Detailed Product Description
Warranty: One Year Penetration: 34mm Steel
Cooling/Duty Cycle: Oil Cooling/100% Film Safety: Guarantee ISO1600 Film
Conveyor Speed: 0.22m/s Conveyor Max Load: 170kg



Security Inspection MCD-6550 Airport X-ray Scanner, X ray Baggage Scanner



Quick Detail

  • 1. Tunnel Size: 500(W)*300(H)mm
  • 2. Conveyor Speed: 0.22m/s
  • 3. Conveyor Max Load: 170kg
  • 4. Dose per Inspection: <2.9 uGy/h
  • 5. Resolution: <0.101mmMetal Wire
  • 6. Spatial resolution Level:diaφ1.0mm , Vertical:diaφ1.0mm
  • 7. Through resolution:φ0.202mm
  • 8. Penetration: 34mm Steel
  • 9. Film Safety: Guarantee ISO1600 Film
  • 10. X-ray Leakage: <0.05 uGy/h (at a distance of 5cmFrom external housing)



X-ray Generator

  • 1. Generate direct: Upward
  • 2. Generate angle: 80 degree
  • 3. Anode Voltage: 80Kv
  • 4. Anode power: 0.4 to 0.5mA
  • 5. Cooling / Duty Cycle: Oil Cooling /100%



Image System

X-ray Sensor  L-Shaped Photodiode Array (monoenergetic) , 12bit Deep
Monitor High Resolution Color, LCD Accord, 17 inch
Detector 1
Color display less than 4 color
Image Processing

Edge enhancement, image strengthening, Image lightening,

reducing  darkening, image returning, image retrieval.

Image Grey Level 4096
Image Max Resolution 1024 * 1280 pixel
Image Processing 24bit for processing real time
Image storage Storage 60000 pictures in real time
Zones & Zoom

1-9 Image regions, 2,4,8,16 Times Enlarge, Whole screen

 continuous observation



Installation Data

  • 1. Operating Temperature/Humidity: 0℃~45℃/20%-95%(non-condensing)
  • 2. Storage Temperature/Humidity-26℃~60/20%-95%(non-condensing)
  • 3. Operation Power:220AVC/(±10)50Hz±3Hz
  • 4. Power Consumption:1.0KW(Max),0.3KW(working)
  • 5. Noise: <55 dB

Feature and Application:

X-rays through inspection,Which show object interior metal structure by LCD screen.Applied

 to factory inspection products and institutions of the security. Such as electronic factory,

shoe factories, toy factories, court and station, as well as large activities handbag security.

MCD -6550 Airport X ray Scanner , X ray Baggage Scanner 34mm steel Penetration

MCD -6550 Airport X ray Scanner , X ray Baggage Scanner 34mm steel Penetration

MCD -6550 Airport X ray Scanner , X ray Baggage Scanner 34mm steel Penetration
